Technical Details

• Package / Case 4-PLCC
• Color Red, Green, Blue (RGB)
• Size / Dimension 3.20mm L x 2.80mm W
• Mounting Type Surface Mount
• Millicandela Rating 540mcd Red, 1600mcd Green, 350mcd Blue
• Configuration Common Anode
• Voltage - Forward (Vf) (Typ) 2.1V Red, 3.1V Green, 3.1V Blue
• Lens Color White
• Current - Test 20mA Red, 20mA Green, 20mA Blue
• Viewing Angle 115°
• Height (Max) 1.90mm
• Wavelength - Peak 634nm Red, 522nm Green, 465nm Blue
• Wavelength - Dominant 625nm Red, 530nm Green, 470nm Blue
• Supplier Device Package 4-PLCC
• Lens Transparency Diffused
• Lens Style Round with Flat Top
• Lens Size 2.40mm Dia
