- Product Model TPS56339DDCR
- Brand Texas Instruments
- RoHS 1
- Description IC REG BUCK ADJ 3A SOT23
- Classification Integrated Circuits - ICs
-
PDF
- 3000 0.42
- 6000 0.4
- 15000 0.39
Technical Details
- Package / Case SOT-23-6 Thin, TSOT-23-6
- Output Type Adjustable
- Mounting Type Surface Mount
- Number of Outputs 1
- Function Step-Down
- Current - Output 3A
- Operating Temperature -40°C ~ 125°C (TJ)
- Output Configuration Positive
- Frequency - Switching 500kHz
- Voltage - Input (Max) 24V
- Topology Buck
- Supplier Device Package SOT-23-THIN
- Synchronous Rectifier Yes
- Voltage - Output (Max) 16V
- Voltage - Input (Min) 4.5V
- Voltage - Output (Min/Fixed) 0.8V
